JOYO JDI-48 Reamp and Active Direct Box - Black
JOYO JDI-48 Reamp and Active Direct Box
The JOYO JDI-48 is a versatile tool combining independent reamping and direct injection (DI) functions in a single unit, designed to enhance both live performances and studio recordings. The active DI function operates on 48V phantom power, delivering a high dynamic range that preserves the nuances of your instrument's sound. It features a low-cut filter, -15dB attenuation pad, and polarity reverse options, providing precise control over your signal. The passive reamp function does not require external power and includes a 6.35mm and XLR 2-in-1 input jack, accepting both 6.35mm TRRS and XLR connections, facilitating seamless integration with various equipment setups.
Key Features
- Dual Functionality: Independent reamping and DI capabilities in one compact unit.
- Active DI with Phantom Power: Operates on 48V DC phantom power, ensuring high dynamic range and signal integrity.
- Passive Reamp Function: Requires no external power, allowing for straightforward reamping processes.
- Comprehensive Controls: Includes low-cut filter, -15dB attenuation pad, and polarity reverse for versatile signal management.
- Versatile Connectivity: Equipped with 6.35mm and XLR 2-in-1 input jack, accepting both 6.35mm TRRS and XLR connections.
- Ground Lift Switch: Eliminates ground loop hum by disconnecting the internal ground channel between input and output.
- Durable Construction: Housed in a robust aluminum alloy casing, ensuring reliability in various environments.
Specifications
| Specification | Details |
|---|---|
| DI Box Type | Active (48V DC phantom power) |
| DI Input Impedance | 220KΩ, unbalanced |
| DI Output Impedance | 600Ω, balanced |
| Frequency Response | 10Hz – 20kHz < -0.5dBv |
| Total Harmonic Distortion | < 0.01% |
| Phase Distortion | -21° |
| Maximum Input Voltage | < 9VPP |
| Reamp Input Impedance | 600Ω |
| Reamp Input Signal Level | +4dB Line level |
| Dimensions (L x W x H) | 146mm x 76mm x 34mm |
| Weight | 467g |
