PROEL DIVA15A – Professional Active Loudspeaker
PROEL DIVA15A – Professional 15″ Active Loudspeaker
The PROEL DIVA15A is a 2-way active loudspeaker with integrated digital signal processing (DSP), delivering high power, clarity, and reliability for live performances, DJ setups, PA systems, and stage monitoring. Equipped with a 15″ woofer and a 1″ compression driver, it provides extended low-end response, smooth mids, and crystal-clear highs. With Bluetooth streaming, multiple inputs, and versatile DSP presets, it adapts to a wide range of professional sound applications.
Housed in a rugged yet lightweight polypropylene cabinet with ergonomic handles, flying points, and monitor-angle design, the DIVA15A ensures durability, portability, and flexible deployment for any performance environment.
Key Features
- Powerful 2-way design: 15″ woofer with 2.5″ voice coil + 1″ titanium compression driver.
- High output: 1000 W peak Class D amplification for strong and clean performance.
- Advanced DSP: FIR filters, 24-bit converters, and 5 selectable presets (MUSIC, LIVE, DJ, MONITOR, SPEECH).
- Integrated 3-channel mixer: Multiple MIC/LINE inputs, stereo mini-jack, and wireless USB ports.
- Bluetooth streaming: Supports TWS stereo linking for wireless audio setups.
- Professional build: Polypropylene cabinet with pole mount, flying points, and wedge monitor capability.
Specifications
| Attribute | Value / Details |
|---|---|
| System Type | 2-way active loudspeaker (vented enclosure) |
| Woofer | 15″ long-excursion woofer, 2.5″ voice coil |
| HF Driver | 1″ compression driver, 1.35″ voice coil, titanium diaphragm |
| Horn Coverage | 90° horizontal × 60° vertical |
| Amplifier Power | 1000 W peak (LF: ~400 W Class D, HF: ~100 W) |
| Frequency Response | ~45 Hz – 20 kHz |
| Maximum SPL | 129 dB |
| Inputs | 2 × MIC/LINE combo (XLR / ¼″), 1 × stereo LINE (3.5 mm mini-jack), 2 × USB wireless ports |
| Outputs | 1 × XLR (adjustable MIX OUT / CH1 LINK) |
| DSP & Presets | FIR filters, 24-bit processing, 5 modes (MUSIC, LIVE, DJ, MONITOR, SPEECH) |
| Controls / Display | Rotary encoder, color LCD, input selectors, EQ controls |
| Bluetooth | Audio streaming, Stereo Link (TWS) |
| Cabinet | Polypropylene, lightweight and rugged |
| Mounting | 35 mm pole socket, 4 × M10 flying points, 45° wedge monitor angle |
| Dimensions | 421 × 696 × 382 mm |
| Weight | ~19 kg |
| Power Supply | 100–120 V / 220–240 V (switchable), 50/60 Hz, ~300 W consumption |
Why Choose the PROEL DIVA15A?
- Extended low-end response: Ideal for DJs, live bands, and full-range PA use.
- Professional DSP control: Tailor the sound to different venues and applications.
- Bluetooth & wireless ready: Stream music or connect Proel U24 wireless mics.
- Built for professionals: Durable polypropylene build with flexible mounting options.
Power, Flexibility, and Reliability
The PROEL DIVA15A delivers high output, extended bass, and precise DSP tuning, making it a trusted solution for events, live music, DJs, and installations. With Bluetooth streaming, versatile inputs, and rugged portability, it’s a loudspeaker designed to perform wherever professional audio is needed.
